Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Power supply type | summable |
| Product or component type | power supply module |
| Range of product | Modicon Quantum automation platform |
| Complementary | |
| Input voltage | 24 V (20...30 V) DC |
| Inrush current | 25 A 24 V, 14 A 20 V |
| Module format | standard |
| Output overload protection | internal |
| Local signalling | 1 LED (green) for power (PWR OK) |
| Net weight | 0.65 kg |
| Power supply output current | 8-8 A summable |
| Alarm output | 1 NC 6 A 220 V power supply fault |
| Input current | 3800 mA |
| Associated fuse rating | 5 A, slow-blow |
| Output overvoltage protection | internal |
| Marking | CE |
| Maximum input power interruption | 1 ms 20 V, 100 ms |
| Output voltage | 5.1 V DC |
| Power dissipation | 6 + (1.8 x Iout) where Iout is in A |
| Environment | |
| Operating altitude | <= 5000 m |
| Resistance to electrostatic discharge | 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2 |
| Relative humidity | 95-95 % without condensation |
| Ambient air temperature for storage | -40-85 °C |
| Standards | UL 508, CSA C22.2 No 142 |
| Resistance to electromagnetic fields | 10 V/m 80-2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0-60 °C |
| Product certifications | FM Class 1 Division 2, cUL |
