Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Mathematical coprocessor | with |
| Processor name | 80486 |
| Software name | Concept, ProWORX 32 |
| Product or component type | processor |
| Range of product | Modicon Quantum automation platform |
| Complementary | |
| I/O words | 64 I/64 O remote, 64 I/64 O max local, 30 I/32 O distributed |
| Memory description | internal RAM 2972 kB |
| Battery capacity | 1.2 Ah |
| Module format | standard |
| Switch function | key switch |
| Number of network | 3 distributed, 2 remote |
| I/O words/network | 500 I/500 O distributed |
| Bus current requirement | 1250 mA |
| Exact time for 1 Kinstruction | 0.1...0.5 ms LL984 |
| Battery life | 10 year(s) |
| Clock frequency | 100 MHz |
| Net weight | 0.85 kg |
| Marking | CE |
| Clock drift | +/-8 s/day at 0-60 °C |
| Battery type | lithium 10 µA 420 µA |
| Watchdog timer | 250-250 ms |
| Number of drops | 31 remote |
| Drops/network | 63 distributed |
| Environment | |
| Operating altitude | <= 5000 m |
| Resistance to electrostatic discharge | 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2 |
| Relative humidity | 95-95 % without condensation |
| Ambient air temperature for storage | -40-85 °C |
| Standards | UL 508, CSA C22.2 No 142 |
| Resistance to electromagnetic fields | 10 V/m 80-2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0-60 °C |
| Product certifications | cUL, FM Class 1 Division 2 |
