Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Range of product | Modicon Quantum automation platform |
| Product or component type | DIO head-end adaptor |
| Complementary | |
| Bus current requirement | 750 mA |
| Optical transmission | -3.5-110.5 dBm 62.5/125 µm, -19.8--12.8 dBm 50/125 µm, -16--9 dBm 100/140 µm |
| Power dissipation in W | 4 W |
| Wavelength | 820 nm |
| Minimum pulse width distortion/jitter | 5 ns |
| Dynamic range | 20 dB |
| Checks | checksum, processor, RAM address, RAM |
| Transmission rate | 1 Mbit/s |
| Number of port | 1 Modbus RS232 twisted pair, 1 Modbus Plus fiber optic single copper |
| Detected silence | -36 dBm |
| I/O words | 30 I/32 O |
| Rise/fall time | 20 ns |
| Electrical connection | 2 connectors TX/RX, 1 connector RJ45 |
| Sensitivity scale | > 30 dBm |
| Power loss budget | 6.5 dB 50/125 µm, 16.5 dB 100/140 µm, 11 dB 62.5/125 µm |
| Environment | |
| Resistance to electrostatic discharge | 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2 |
| Relative humidity | 95-95 % without condensation |
| Ambient air temperature for storage | -40-85 °C |
| Resistance to electromagnetic fields | 10 V/m 80-2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0-60 °C |
| Operating altitude | <= 5000 m |
| Standards | UL 508 |
| Product certifications | DNV, GOST, C-Tick, RMRS, GL, RINA, CSA Class 1 Division 2 |
