This is a MN undervoltage release for Compact NS80H-MA and Compact NSC100N devices. Its rated voltage is 110VAC to 130VAC 50/60Hz. It is an auxiliary used for emergency off or remote opening applications. This auxiliary opens the circuit breaker when the control voltage drops to a value below 35% of its rated voltage Un. It complies with IEC 60947-2 standard. Compact NS80H-MA and Compact NSC100N devices can be equipped with either 1 MX or 1 MN auxiliary.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Device short name | MN |
| Device application | control |
| Voltage release type | undervoltage release |
| Range | ComPacT |
| Product or component type | voltage release |
| Range compatibility | ComPact Compact NG, ComPact Compact NSE, ComPact Compact NSC, ComPact ComPact NS |
| Range of product | NSC100, NSA125...160, NG160NA, NS80H-MA, NSE75...100, NG160 |
| [Uc] control circuit voltage | 110...130 V AC 50/60 Hz |
| Complementary | |
| Threshold tripping voltage | 0.85 Un closing, 0.35...0.7 Un opening |
| Response time | < 50 ms |
| Auxiliary connection terminal | screw terminal 0-1.5 mm² |
| Supply holding power | < 5 VA |
