Asense series is a device measures both carbon monoxide and carbon dioxide and therefore is ideal for measuring air quality for health purposes in indoor carparks and traffic tunnels It is intended for duct mounting. Energy efficiency can be achieved by using the measurement(s) to vary the fan speed of the fresh air supply equipment.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| IP degree of protection | IP65 |
| Device application | outdoor reference |
| Depth | 46 mm |
| Display type | LCD |
| Output type | relay normally open, relay normally close |
| Width | 85 mm |
| CO2 measurement accuracy | +/- 5 % of measured value, +/- 1 % of measurement range |
| Local signalling | red LED active open collector output, green LED relay closed, yellow LED maintenance support |
| Relative humidity | 0-95 % RH, non-condensing |
| Sensor type | NDIR (non-dispersive infrared) with ABC (automatic baseline correction) carbon dioxide (CO2), fuel type electrochemical with temperature compensation carbon monoxide (CO) |
| Service life | 5 year(s) |
| Temperature measurement accuracy | +/- 10 ppm, +/- 5 % of measured value, +/- 1 % of measurement range |
| Ambient air temperature for storage | -20-70 °C |
| Directives | 89/336/EEC - electromagnetic compatibility |
| CO measurement accuracy | +/- 10 ppm |
| CO2 measurement range | 0...3000 ppm |
| Type of measurement | carbon monoxide (CO) and nitrogen dioxide (NO2), carbon dioxide (CO2) |
| Targeted region | Asia Pacific., Europe |
| Mounting support | duct |
| CO measurement range | 100...500 ppm |
| Analogue output type | 4...20 mA |
| Calibration certificate | humidity: none |
| Ambient air temperature for operation | 0-50 °C |
| Height | 150 mm |
| Setpoint | No |
| Sensor model | 040-8-0066 |
| With override | No |
