This Acti9 product is a set of 4 temperature sensors. It is based on Zigbee communication port protocol on a transmission frequency of 2.405GHz according to IEEE802.15.4 standard. It is intended for fridge.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Concentrator compatibility | wireless access point |
| Range | Acti9 |
| Product or component type | temperature sensor |
| Product destination | fridge |
| Complementary | |
| Depth | 40 mm |
| Width | 40 mm |
| Colour | white |
| Display type | 1 LED (green) for communication status |
| Quantity per set | set of 4 |
| Maximum radio power | 4 dBm |
| Maximum sensing distance | 100 m in free field |
| Net weight | 15 g |
| Supply | internal battery |
| Communication port protocol | Zigbee green power at 2.405 GHz conforming to IEEE 802.15.4 |
| Fixing mode | by clamp, by 2 screws, adhesive tape |
| Standards | ETSI EN 300 328, ETSI EN 301 489-17, ETSI EN 301 489-1, EN 62311:2007, EN 61326-1, EN 61000-6-3, EN 61000-6-1, IEC 60950 |
| Range compatibility | Harmony XB5R ZBRA wireless and batteryless range |
| Accuracy | +/- 1 °C |
| Height | 15 mm |
| Cycle duration | 2 min for measuring and transmission |
| Environment | |
| Relative humidity | 0-95 % |
| IP degree of protection | IP65 |
| Product certifications | IC, FCC |
| Ambient air temperature for operation | -30-55 °C |
