This product is part of the Modicon ABE7 range, an offer of connection sub-bases for pre-wired system. This is an electromechanical plug-in relays for 24VDC prewired sub-bases. It has 1 NO contact. Its mechanical durability is up to 20000000 cycles. It immunity to microbreaks is up to 1ms. It is used to to control the power along with switching the smaller current values in a control circuit. It is 5mm wide. It weighs 0.005kg. It is suitable into any types of industrial applications needing rapid connection of I/O modules (digital, analog, and counter) to operative parts. It is suitable for use with ABE7R16T111, ABE7R16M111, ABE7P16M111, and ABE7P16T111 sub-bases. It is delivered in 1 package (PCE type) containing 4 units. Modicon ABE7 means greater simplicity to rationalise wiring in automation system equipment.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Quantity per set | set of 4 |
| Product or component type | plug-in electromechanical relay |
| Range of product | Advantys Telefast ABE7 |
| Control circuit type | DC |
| Complementary | |
| Drop-out current | 0.5 mA at 20 °C |
| Threshold tripping voltage | 16.8 V at 40 °C |
| [Uc] control circuit voltage | 24 V |
| Product compatibility | ABE7P16T111, ABE7P16M111, ABE7R16M111, ABE7R16T111 |
| Operating rate in Hz | 0.1 Hz at Ie, 20 Hz no load |
| Drop-out voltage | 2 V at 20 °C |
| Mechanical durability | 20000000 cycles |
| Contacts type and composition | 1 NO |
| Maximum switching voltage | 30 V DC conforming to IEC 60947-5-1, 250 V AC 50/60 Hz conforming to IEC 60947-5-1 |
| Width pitch dimension | 5 mm |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-1 |
| Net weight | 0.005 kg |
| Electrical durability | 500000 cycles, maximum switching current: 500 mA at 24 V DC-13 10 ms, 500000 cycles, maximum switching current: 400 mA at 230 V AC-15, 500000 cycles, maximum switching current: 3000 mA at 24 V DC-12, 500000 cycles, maximum switching current: 2000 mA at 230 V AC-12 |
| Associated fuse rating | 1 A, fast blow |
| [Ith] conventional free air thermal current | 6 A |
| Maximum power dissipation per pole | 0.17 W |
| Minimum switching current | 100 mA at >= 5 V |
| Environment | |
| Max immunity to microbreaks | 1 ms |
| Dielectric strength | 4000 V conforming to IEC 60947-1 |
