ComPacT NSX 100F is a complete 2 poles fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 36kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 100A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 2 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. ComPacT NSX100F is part of Schneider Electric EcoStruxure Power architecture.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Device application | distribution |
| Suitability for isolation | yes conforming to EN/IEC 60947-2 |
| Trip unit technology | thermal-magnetic |
| Utilisation category | category A |
| Network type | DC, AC |
| Device short name | NSX100F |
| Breaking capacity code | F 18 kA 415 V AC |
| Breaking capacity | 36 kA Icu at 500 V DC 50/60 Hz 2 poles in series conforming to IEC 60947-2, 36 kA Icu at 250 V DC 50/60 Hz 1 pole conforming to IEC 60947-2, 5 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2, 10 kA Icu at 500/525 V AC 50/60 Hz 2P conforming to IEC 60947-2, 15 kA Icu at 440 V AC 50/60 Hz 1P conforming to IEC 60947-2, 18 kA Icu at 380/415 V AC 50/60 Hz 1P conforming to IEC 60947-2, 36 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 |
| Mounting mode | fixed |
| Control type | toggle |
| Range | ComPacT new generation |
| Protected poles description | 2D |
| Range of product | ComPacT NSX100...250 DC new generation, ComPacT NSX100...250 new generation |
| Trip unit name | TM-D |
| Poles description | 2P |
| Product name | ComPacT NSX new generation |
| Product or component type | circuit breaker |
| Trip unit protection functions | LI |
| [Ue] rated operational voltage | 500 V DC, 690 V AC 50/60 Hz |
| [In] rated current | 100 A at 40 °C |
| Network frequency | 50/60 Hz |
| Complementary | |
| [Uimp] rated impulse withstand voltage | 8 kV conforming to IEC 60947-2 |
| Compatibility code | NSX100 |
| Trip unit rating | 100-100 A at 40 °C |
| Long time pick-up adjustment type Ir | fixed |
| Electrical durability | 10000 cycles at 277 V In, 20000 cycles at 277 V In/2 |
| Downside connection | front |
| Earth-leakage protection | without |
| Height | 161 mm |
| [Ics] rated service breaking capacity | 36 kA at 500 V DC 50/60 Hz conforming to IEC 60947-2, 36 kA at 250 V DC 50/60 Hz conforming to IEC 60947-2, 5 kA at 660/690 V AC 50/60 Hz conforming to IEC 60947-2, 10 kA at 500/525 V AC 50/60 Hz conforming to IEC 60947-2, 15 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2, 18 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2, 36 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Ui] rated insulation voltage | 750 V AC 50/60 Hz conforming to IEC 60947-2 |
| Net weight | 1.2 kg |
| Long time delay adjustment type | fixed |
| Power dissipation per pole | 8.8 W |
| Connection pitch | 35 mm |
| Mechanical durability | 20000 cycles |
| Upside connection | front |
| Long time pick-up adjustment range | 1 x In |
| Protection type | I : for short-circuit protection (magnetic), L : for overload protection (thermal) |
| Depth | 86 mm |
| Width | 70 mm |
| Mounting position | flat on the back, horizontal and vertical |
| Instantaneous pick-up adjustment type Ii | fixed |
| Instantaneous pick-up adjustment range | 800 A |
| Mounting support | backplate |
| Environment | |
| Relative humidity | 0-95 % |
| Ambient air temperature for storage | -50-85 °C |
| Overvoltage category | class II |
| Operating altitude | 2000 m...5000 m with derating, 0...2000 m without derating |
| Electrical shock protection class | class II |
| Product certifications | Marine, EAC, CCC |
| Pollution degree | 3 conforming to IEC 60664-1 |
| IP degree of protection | IP40 conforming to IEC 60529 |
| Ambient air temperature for operation | -25-70 °C |
| IK degree of protection | IK07 conforming to IEC 62262 |
| Standards | EN/IEC 60947 |
