Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Device application | power supply |
| Range | Clipsal - 56 Series |
| Product or component type | plug |
| Range of product | Series 56 |
| Product brand | Clipsal |
| Complementary | |
| Depth | 168 mm |
| Market segment | industry, utility, small commercial |
| Plug, socket category | low voltage |
| Width | 130 mm |
| Colour | body: orange (RAL 2004) |
| Outlet standard | industrial |
| [In] rated current | 40 A |
| Cable entry | cable gland |
| Pin arrangement | O |
| Poles description | 3P + E |
| Material | polycarbonate: housing, plastic |
| Wire stripping length | 20 mm, 50 mm |
| Thread type | M40 |
| Voltage colour | black |
| Colour code | EO |
| Net weight | 0.5 kg |
| Plug, socket, control station shape | angled |
| Contacts material | pins: brass |
| [Ue] rated operational voltage | 500 V AC 50 Hz conforming to EN 60309-2 |
| Duration | 7 h |
| Height | 78 mm |
| Targeted country | Australia |
| Connections - terminals | screw terminal 2.5-25 mm² |
| Environment | |
| IP degree of protection | IP66 conforming to AS 60529 |
| Standards | AS/NZS 3123 |
| Ambient air temperature for operation | -25-75 °C |
