Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Colour | cover: grey |
| Range | Clipsal - 56 Series |
| Suitability for isolation | yes |
| Product or component type | switch |
| Handle colour | grey |
| Complementary | |
| Tightening torque | 0.8 N.m |
| Control type | rotary knob |
| Targeted country | Australia |
| Breaking capacity | 40 kA at 500 V (AC-21A) |
| Market segment | small commercial, utility, industry |
| Poles description | 3P |
| Motor M-rating AS3133 | M220 at 690 V |
| Rated current | 40 A |
| [Ue] rated operational voltage | 500 V AC 50 Hz |
| Rotary handle padlocking | 2 padlocks 8-8 mm |
| Environment | |
| IP degree of protection | IP66 conforming to AS 60529 |
| Standards | AS/NZS 3133 |
