Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Plug, socket category | low voltage |
| Poles description | 1P + N + E |
| Product compatibility | connector Easy56 EY56CSC310 |
| Product or component type | appliance inlet |
| Outlet standard deviation | Australian/New Zealand |
| Accessory / separate part category | connection accessory |
| Network type | AC |
| Pin number | 3 pins |
| Complementary | |
| [Ue] rated operational voltage | 250 V |
| Depth | 102 mm |
| Market segment | utility, small commercial, industry |
| Width | 101 mm |
| Colour | grey (RAL 7035) |
| [In] rated current | 10 A |
| Material | polycarbonate: cover |
| Cable cross section | 1.5-6 mm² |
| Wire stripping length | 10-10 mm |
| Mounting mode | surface mounted |
| Cable stiffness | rigid or stranded |
| Net weight | 0.471 kg |
| Plug, socket, control station shape | straight |
| Contacts material | pins: brass |
| Height | 101 mm |
| Connections - terminals | screw terminals |
| Targeted country | Australia, New Zealand |
| Network frequency | 50 Hz |
| Environment | |
| Quality labels | RCM |
| Ambient air temperature for storage | -25-75 °C |
| IP degree of protection | IP66 conforming to AS 60529 |
| Standards | AS/NZS 60320.1 |
| Ambient air temperature for operation | -25-75 °C |
