Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Plug, socket category | low voltage |
| Poles description | 1P + N + E |
| Product compatibility | plug Easy56 EY56P315 |
| Product or component type | connector |
| Outlet standard deviation | Australian/New Zealand |
| Shape of pin | flat |
| Accessory / separate part category | connection accessory |
| Network type | AC |
| Pin number | 3 pins |
| Complementary | |
| [Ue] rated operational voltage | 250 V |
| Cable outer diameter | 7.4-10.6 mm |
| Depth | 105 mm |
| Market segment | industry, small commercial, utility |
| Width | 65 mm |
| Colour | body: clear, plug: orange (RAL 2004) |
| [In] rated current | 15 A |
| Cable entry | cable gland |
| Material | polycarbonate: housing |
| Cable cross section | 1.5-1.5 mm² |
| Wire stripping length | 12-34 mm |
| Thread type | M20 |
| Net weight | 0.107 kg |
| Plug, socket, control station shape | straight |
| Contacts material | sleeves: brass |
| Height | 65 mm |
| Connections - terminals | screw terminals |
| Targeted country | New Zealand, Australia |
| Network frequency | 50 Hz |
| Environment | |
| Quality labels | RCM |
| Ambient air temperature for storage | -25-75 °C |
| IP degree of protection | IP66 conforming to AS 60529 |
| Standards | AS/NZS 3120 |
| Ambient air temperature for operation | -25-75 °C |
