Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Accessory / separate part type | adaptor |
| Product compatibility | Harmony iPC industrial PCs, Harmony GTU open |
| Accessory / separate part category | adaptation accessory |
| Range of product | Harmony GTU |
| Complementary | |
| Input voltage | 24 V DC, 12 V DC module supply |
| Depth | 35 mm |
| Width | 188 mm |
| Output voltage | 24 V |
| Integrated connection type | 2 Ethernet TCP/IP type RJ45 jack, 1 DIO type terminal block 3 inputs + 1 output |
| Type of cooling | natural |
| Local signalling | LED green, orange and red, alternate for ERROR (fault), LED red, steady for power ON, LED orange, flashing for establishing communication connection, LED green/orange, alternate for program mode, LED green, faded for stand-by, LED green, steady for operating status (RUN) |
| Accessory / separate part destination | Harmony GTU display |
| Net weight | 0.8 kg |
| Output voltage type | DC |
| [Us] rated supply voltage | 12 V DC module supply |
| Output current | 50 mA |
| Height | 131 mm |
| Power consumption in W | 8 W |
| Environment | |
| Operating altitude | 2000 m |
| Resistance to fast transients | 2 kV (power ports) conforming to IEC 61000-4-4, 1 kV (signal ports) conforming to IEC 61000-4-4 |
| Relative humidity | 10-90 % non-condensing |
| Environmental characteristic | dustproof, corrosive gas free |
| Ambient air temperature for storage | -20-60 °C |
| Vibration resistance | 9.8 m/s² constant acceleration (f= 9-150 Hz) X, Y, Z directions for 10 cycles (approx. 100 min) conforming to EN/IEC 61131-2, 3.5 mm constant amplitude (f= 5-9 Hz) X, Y, Z directions for 10 cycles (approx. 100 min) conforming to EN/IEC 61131-2 |
| Shock resistance | 147 m/s² for X, Y, Z directions for 3 times conforming to EN/IEC 61131-2 |
| Electromagnetic compatibility | electrostatic discharge immunity test - test level: 8 kV level 3 (air discharge) conforming to IEC 61000-4-2, electrostatic discharge immunity test - test level: 6 kV level 3 (contact discharge) conforming to IEC 61000-4-2 |
| Pollution degree | 2 |
| Ambient air temperature for operation | 0-60 °C |
| Product certifications | UKEX, UKCA, EAC, ATEX zone 2/22, IEC-Ex, cULus HazLoc Class I Division 2 ANSI/ISA 12-12-01, CSA C22-2 No 213, CSA C22-2 No 142, UL 508 |
