This digital input module is part of the range Modicon TM2 expansion modules. It consists in 16 digital inputs with sink / source logic and it works at 24V dc rated power supply. It is equipped with one removable screw terminal block and can be mounted on a symmetrical DIN rail 35 mm. It is compatible with Modicon OTB interface modules, Magelis HMI controller XBTGC and Modicon / Twido controllers.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Discrete input number | 16 |
| Product or component type | I/O expansion module |
| Discrete input voltage type | DC |
| Discrete input voltage | 24 V |
| Range of product | Modicon M238 logic controller |
| Complementary | |
| Number of common point | 1 |
| Range compatibility | Advantys OTB, Twido |
| Input impedance | 3.4 kOhm |
| Local signalling | 1 display block |
| Discrete input logic | sink or source |
| Isolation between channels and internal logic | 500 V for 1 minute |
| Isolation between channels | none |
| Net weight | 0.065 kg |
| Input voltage limits | 20.4...28.8 V |
| Discrete input current | 7 mA |
| Current consumption | 40 mA at 5 V DC at state 1 for all input |
| Response time | 4 ms at state 1 , 4 ms at state 0 |
| Mounting support | 35 mm symmetrical DIN rail |
| Electrical connection | 1 removable screw terminal block |
| Environment | |
| Depth | 84.6 mm |
| Width | 23.5 mm |
| Height | 90 mm |
