TeSys Deca suppressor module, for LC1D09-D38, LC1DT20-DT40 contactors and CAD control relays. To be used with 12-24V AC control circuit voltage, it provides a bidirectional peak limiting diodes protection limiting the transient voltage to 2 Uc max. Clip-on side mounting, overall size of the contactor is unchanged. Sustainability compliant.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Device short name | LAD4 |
| Product compatibility | CAD32, CAD50, 4P LC1D098...D258, 4P LC1DT20...DT40, 3P LC1D09...D38 |
| Range | TeSys |
| Product or component type | suppressor module |
| Range of product | TeSys Deca control relay, TeSys Deca |
| Complementary | |
| Suppressor technology | bidirectional peak limiting diode |
| Compatibility code | LAD4 |
| Mounting mode | by clips |
| Maximum peak voltage | 2 Uc |
| Mounting location | side |
| Net weight | 0.012 kg |
| [Uc] control circuit voltage | 24 V AC |
| Environment | |
| Ambient air temperature for storage | -40-80 °C |
| IP degree of protection | IP2X conforming to IEC 60529 |
| Standards | GB/T 14048.5, UL 60947-5-1, CSA C22.2 No 60947-5-1, EN 60947-5-1, IEC 60947-5-1 |
| Ambient air temperature for operation | -25-55 °C |
| Product certifications | CSA, UL |
