This device is a rated current 320A circuit breaker from EasyPact CVS400F. The rated breaking capacity(Ics) is 36kA at 415VAC,and complete range with Ics=100%Icu. The version of breaker is 3poles frame with detection on 3poles, also accompanied MA trip unit for magnetic protection. It is conformed to standard IEC60947-2 for circuit breakers part. This device is certified for operation in pollution degree III environment as defined IEC60947-1& IEC60664-1, and respected for RoHs requirement as european environment directive EC/2002/95. It can be mounted by blackplate or Din rail,also through the door of class II switchboard without downgrading switchboard insulation. The front of toggle offers IP40 protection, but when it is equiped extended rotary handle inside the switchboard, additional IP54 protection degree for extended rotary handle. This series have slots for electrical auxiliaries(MN/MX/OF/SD),depending on the type of trip unit if rotary handle installed. The fixed dimension is 140mm width.255mm height,110mm depth,
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Device short name | CVS400F |
| Device application | motor |
| Protection type | short-circuit protection (magnetic) |
| Trip unit rating | 320-320 A at 40 °C |
| Breaking capacity | 30 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2, 36 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2, 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 |
| Range | EasyPact |
| Protected poles description | 3D |
| Earth-leakage protection | without |
| Range of product | EasyPact CVS400...630 |
| Trip unit name | MA |
| Trip unit technology | magnetic |
| Poles description | 3P |
| Utilisation category | category A |
| Product name | EasyPact CVS |
| Product or component type | circuit breaker |
| Network type | AC |
| [In] rated current | 320 A at 40 °C |
| Complementary | |
| Short-time pick-up adjustment type Isd | adjustable |
| [Uimp] rated impulse withstand voltage | 8 kV conforming to EN/IEC 60947-2 |
| Compatibility code | CVS400 |
| Mechanical durability | 15000 cycles |
| Electrical durability | 6000 cycles 415 V In conforming to IEC 60947-2 |
| Mounting mode | fixed |
| Upside connection | front |
| Control type | toggle |
| Downside connection | front |
| Connection pitch | 45 mm |
| Height | 255 mm |
| [Ics] rated service breaking capacity | 23 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2, 36 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2, 40 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 |
| Depth | 110 mm |
| Width | 140 mm |
| [Isd] short-time pick-up adjustment range | 6...13 x In |
| Net weight | 4.7 kg |
| Instantaneous pick-up adjustment type Ii | adjustable |
| Instantaneous pick-up adjustment range | 6...13 x In |
| Breaking capacity code | F |
| Mounting support | backplate |
| Contact position indicator | yes |
| Connections - terminals | screw connection |
| Network frequency | 50/60 Hz |
| Environment | |
| Ambient air temperature for storage | -50-85 °C |
| Pollution degree | 3 conforming to IEC 60664-1 |
| IP degree of protection | IP40 |
| Ambient air temperature for operation | -25-70 °C |
| Electrical shock protection class | class II |
| Standards | IEC 60947-2, EN 60947-2 |
| Product certifications | IEC, GOST |
