Act (MK-2690): Pneu, 2Pos/Prop, Slt PSIG, SR, Air NPT, Linear, N1

Manufacturer: Schneider Electric

SKU: MK-2690

GTIN: 711426530674

Environmental Disclosure

Old price: $151.14 inc GST

Price: $199.88 inc GST

Qty:

Supported cards

Act (MK-2690): Pneu, 2Pos/Prop, Slt PSIG, SR, Air NPT, Linear, N1

Products specifications

Attribute name	Attribute value
Main
Diaphragm effective area	6 in²
Material	die cast aluminium: housing
IP degree of protection	IP10
Relative humidity	5-95 % non-condensing
Ambient air temperature for storage	-40-104.4 °C
Product destination	globe valve
Control type	manual override with 5/32 allen wrench
Product or component type	actuator
Targeted region	North America.
Actuator	linear
Ambient air temperature for operation	-28.8-104.4 °C

Power loss return	spring return
Positioner	False
Material diaphragm	neoprene
Control signal	proportional/modulating, 2-position (on/off)
Lead length	1/8 in
Stroke auto calibration	False
Leads and connections	air NPT
Control spring range	8...13 psig, 5...10 psig, 3...7 psig
Actuator type	pneumatic
Actuator product series	MK-2690
Position indicator	green push stem with color markers
