The SpaceLogic DI-16 is a digital input, 16 channel I/O expansion module for the SpaceLogic AS-P Server. The digital inputs can be used for sensing of multiple dry contact digital inputs in applications such as equipment status and alarm point monitoring. As counter inputs, digital inputs are commonly used in energy metering applications. The DI-16 I/O expansion module features 16 digital inputs. Its dimensions are 114 mm (4.5 in.) in height, 90 mm (3.6 in.) in width and 64 mm (2.5 in.) in depth. This I/O module requires a SpaceLogic Central I/O Terminal Base (SXWTBIOW110001).
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| IP degree of protection | IP20 |
| Device short name | DI-16 |
| Depth | 64 mm |
| Width | 30 mm |
| Relative humidity | 0-95 % non-condensing |
| Power consumption in VA | 1.6 W |
| Ambient air temperature for storage | -20-70 °C |
| Flame retardance | UL94V0-5VB |
| Range | EcoStruxure Building Operation |
| Net weight | 194 g |
| Product name | I/O Modules |
| Input/output type | digital input |
| Product or component type | I/O module |
| Ambient air temperature for operation | 0-50 °C |
| Height | 114 mm |
| Product brand | Schneider Electric |
| Product certifications | RCM, CE, FCC part 15 class B, ICES-003 |
| Complementary | |
| Electrical connection | plug-in sub-base |
| Material | ABS + PC |
| Discrete input number | 16 |
| Control type | without |
| Local signalling | LED (green/red) for low signal level, LED (green/red) for high signal level |
| Range compatibility | EcoStruxure Building Operation TB-IO-W1 terminal base |
| Standards | FCC CFR 47 part 15, UL 916, UL 864 |
| Mounting support | DIN rail, wall |
| Discrete input voltage | 24 V |
| Switching frequency | 25 Hz |
