Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Transmission rate | <= 512 kbits/s |
| Product or component type | remote radio |
| Range of product | Trio License Free Radios |
| Network frequency | 921...928 MHz (New Zealand) |
| Complementary | |
| Radio power | 30.0 dBm |
| Net weight | 0.5 kg |
| Length | 100.0 mm |
| Width | 165.0 mm |
| Operating mode | layer-2 ethernet bridge mode |
| Channel access management | channelshare collision avoidance |
| Housing material | die cast aluminium |
| Connector type | power supply: 1.0 x screw terminal (2.0 poles) |
| Communication service | time stamped events management, TCP/UDP serial server, SNMP client/server, NTP client/server |
| Communication gateway | Modbus gateway |
| Power range | 2.1 W: receive |
| Mounting support | direct mounting, DIN rail |
| Communication port protocol | SSH, Telnet, HTTPS, HTTP, ICMP, SNMP v2, SNMP v1, UDP (User Datagram Protocol), TCP (Transmission Control Protocol) |
| Height | 34.0 mm |
| Function available | diagnostic with Telnet/SSH, diagnostic via web server, remote configuration with Telnet/SSH, configuration via web server |
| Integrated connection type | antenna, TNC socket, 2 serial port, DE-9 RS232/RS485, 300...115200 bps, Ethernet port, 2 RJ45, 10/100 Mbps |
| Input voltage | 10...30 V DC |
| Environment | |
| IP degree of protection | IP41 |
| Relative humidity | 5-95 % 40 °C |
| Standards | CSA C22.2 No 213 Class I Division 2 Group D, CSA C22.2 No 213 Class I Division 2 Group C, CSA C22.2 No 213 Class I Division 2 Group B, CSA C22.2 No 213 Class I Division 2 Group A, AS/NZS 4268 |
| Ambient air temperature for storage | -40-85 °C |
| Ambient air temperature for operation | -40-70 °C |
| Product certifications | CSA |
