ConneXium Extended Managed Switch - 8 ports for copper - Coated

Manufacturer: Schneider Electric

SKU: TCSESM083F23F1C

GTIN: 3595864115467

User guide

Declaration of conformity

Old price: $5,599.00 inc GST

Price: $7,404.68 inc GST

Qty:

Supported cards

Specifications
Reviews

Products specifications

Attribute name	Attribute value
Main
Concept	Transparent Ready
Cybersecurity	port hardening
Product specific application	for severe environments
Communication port protocol	MRP (Media Redundancy Protocol), SNTP, Telnet, LLDP, RS232, SNMP, HTTPS, HTTP, SSH, Ethernet TCP/IP
Product or component type	Ethernet TCP/IP managed switch
Port Ethernet	10/100BASE-TX - 8 port(s) copper cable
Range of product	ConneXium
Maximum number of switches in cascade	unlimited
Complementary
Depth	115 mm
Width	120 mm
Diagnostics run time	self test, signal contact
Local signalling	Device status, 1 LED per channel (green/yellow) for channel diagnostic, 1 LED (yellow) for signal contact 2, 1 LED (yellow) for signal contact 1, 1 LED (red) for stand-by, 1 dual colour LED (green/yellow) for ring manager, 1 LED (red) for fault, 1 dual colour LED (green/yellow) for P1 P2 power supplies
Supply voltage limits	18-60 V DC SELV
Ethernet cabling system	TF switches
Ethernet service	SNMP-Traps and SYSLOG, IGMP Snooping, data stream control, multicast filtering, VLAN, configuration via web server
Function available	Trap log, report, system information, alarms (Traps)
Maximum number of switches in a ring	50
Electrical connection	2 removable connectors 2 ways power supply
Net weight	1 kg
Redundancy	redundant network coupling, RSTP, HiPER ring
Alarm output	2 voltfree contact 2 A
Marking	ATEX, RCM, UL, CE
Communication service	address conflict detection, port mirroring, port monitoring, Quality of Service (QoS), TFTP
Power consumption in W	10 W
Mounting support	35 mm symmetrical DIN rail
Transmission support medium	twisted shielded pairs cable CAT 5E for copper cable
Integrated connection type	shielded RJ45 copper cable
Alarm function	external memory removed, temperature threshold, data link status, power supply fault
Height	137 mm
[Us] rated supply voltage	24...48 V
Maximum cable distance between devices	100 m copper cable
Environment
IP degree of protection	IP30
Protective treatment	conformal coating
Relative humidity	10-95 % non-condensing
Directives	2014/30/EU - electromagnetic compatibility, 2014/35/EU - low voltage directive
Product certifications	BV, GL, LR, ATEX, RCM, UL, CE
Standards	UL 1604 Class 1 Division 2, CSA C22.2 No 213 Class I Division 2, IEC 61850-3, EN/IEC 61131, UL 508
Ambient air temperature for operation	-40-85 °C
