Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Discrete output number | 16 |
| Discrete output voltage | 48...240 V AC conforming to EN/IEC 61131-2 41...264 V |
| Product or component type | discrete output module |
| Range of product | Modicon Premium Automation platform |
| Discrete output type | triac protected |
| Complementary | |
| Module format | standard |
| Short-circuit protection | 5 A, integrated fuse fast blow |
| Net weight | 0.31 kg |
| Response time | < 10 ms (deactivation), < 10 ms (activation) |
| Output overvoltage protection | Ge-Mov |
| Marking | CE |
| Output overload protection | 5 A, integrated fuse fast blow |
| Current consumption | 220 mA at 5 V DC |
| Insulation resistance | > 10 MOhm 500 V |
| Electrical connection | screw terminal block |
| Current per channel | 1 A |
| Maximum current per module | 12 A |
| Power dissipation | (0.85 W + 1 W x No of outputs x current per module) |
| Environment | |
| Operating altitude | 0...2000 m |
| IP degree of protection | IP20 |
| Protective treatment | TC |
| Relative humidity | 5-95 % without condensation for storage, 10-95 % without condensation for operation |
| Ambient air temperature for storage | -25-70 °C |
| Dielectric strength | 2000 V 50/60 Hz 60 s |
| Pollution degree | 2 |
| Standards | CSA C22.2 No 142, 92/31/EEC, CSA C22.2 No 213 Class I Division 2 Group A, CSA C22.2 No 213 Class I Division 2 Group C, CSA C22.2 No 213 Class I Division 2 Group D, 93/68/EEC, UL 508, 89/336/EEC, CSA C22.2 No 213 Class I Division 2 Group B, 73/23/EEC, IEC 61131-2 |
| Ambient air temperature for operation | 0-60 °C |
| Product certifications | RINA, DNV, BV, GL, LR, RMRS, ABS |
