| Attribute name | Attribute value |
|---|---|
| Main | |
| Saturated steam temperature | -7-171 °C |
| Seating seal material | PTFE (polytetrafluoroethylene) |
| Seat leakage | Port A: Class V, Port A: Class IV (0.01 %) |
| Operating fluid temperature | -7-171 °C |
| Product or component type | valve |
| Targeted region | North America. |
| Body material | bronze |
| Satured steam inlet pressure | 100 psi |
| Seat material | Port A: stainless steel 316 |
| Valve product range | Venta |
| Pressure allowable static | 400 psig up to 150 °F decreasing to 321 psig at 281 °F |
| Valve type | globe |
| Packing material | spring-loaded PTFE/EPDM |
| Flow characteristic | linear |
| Trim material | stainless steel |
| Stroke length | 7/16 in |
| Stem material | stainless steel 316 |
| Control valve rangeability | 100:1 |
| Pressure fluid max delta P quiet service | 35 psi |
| Plug material | stainless steel |
| Valve product series | VB-7200 |
| Pipe size | 1-1/4 in |
| Body pattern | straightway |
| Flow coefficient | 17.3 kvs, 20 cv |
| Stem flow action | Stem up A closed |
| Valve configuration | 2-Way |
| Stem movement | linear |
| Pressure fluid max delta P normal life | 87 psi |
| Pressure class | ANSI class 250 |
| Body size | 32 mm (1-1/4 in) |
