Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Function of module | monitoring short-circuit and line break for remote line control output, monitoring safety dialogue for discrete input, monitoring safety detection for discrete input |
| Safety use category | SIL 3 conforming to EN/IEC 61508, performance level e conforming to EN/ISO 13849-1, category 4 maximum conforming to EN 954-1 |
| Discrete input number | 16 not isolated discrete input(s) |
| Safety module application | extension of I/O capacity |
| Safety module name | XPSMF1 |
| Structure type | 10BASE-T/100BASE-TX |
| Supply | SELV or PELV conforming to EN/IEC 60950 |
| Product or component type | Preventa safety remote input module |
| Number of outputs | 4 not isolated for line control outputs |
| Range of product | Preventa Safety automation |
| [Us] rated supply voltage | 24 V DC - 15...20 % |
| Complementary | |
| Depth | 66.5 mm |
| Width | 152 mm |
| Switching voltage | 7.5 V for discrete input |
| Input protection type | protected against short-circuit |
| Switching time | 250 µs for discrete input |
| Response time | depending on size of application |
| Current state 0 guaranteed | 1...1.5 mA (discrete input) |
| Voltage state 1 guaranteed | >= 15 V for discrete input |
| Nominal output current | 60 mA for line control outputs |
| Communication port protocol | safe Ethernet with 2 RJ45 port(s), transmission rate: 100 Mbps, 10 Mbps, medium: dual twisted pair cable, category 5D or better |
| Voltage state 0 guaranteed | <= 5 V for discrete input |
| Net weight | 0.7 kg |
| Current state 1 guaranteed | >= 2 mA (discrete input) |
| Discrete input current | 40 mA |
| Current consumption | 0.8 A at 24 V DC on power supply |
| Exchange mode | half duplex, full duplex, autonegotiation |
| Mounting support | 35 mm symmetrical DIN rail |
| Discrete input voltage | 19.2 V |
| Height | 109 mm |
| Output voltage | 20 V line control outputs |
| Number of terminal blocks | 4 for discrete input, 1 for power supply, 1 for discrete output |
| Environment | |
| Ambient air temperature for storage | -40-85 °C conforming to EN 61131-2 |
| IP degree of protection | IP20 |
| Ambient air temperature for operation | 0-60 °C |
