SpaceLogic STP120 series are immersion temperature sensors. It is intended for immersion mounting in pipe systems without requiring a pocket/well.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| IP degree of protection | IP65 |
| Device application | pipe immersion |
| Product compatibility | Vista |
| Depth | 45 mm |
| Colour | black and green |
| Output type | resistive output |
| Width | 65 mm |
| Sensor type | 1.8 kOhm NTC temperature |
| Ambient air temperature for storage | -40-100 °C |
| Location | plant room |
| Ambient air temperature for operation | -40-120 °C |
| Product or component type | sensor |
| Type of measurement | temperature |
| Targeted region | Europe, Asia Pacific. |
| Mounting support | pipe |
| Range of product | STP120 |
| Height | 85 mm |
| Complementary | |
| Measurement accuracy | 0...25 °C +/- 0.3 °C |
| Number of cables | 1 <0.02 m |
| Material | stainless steel: insert pipe, PA (polyamide): connection box |
| Connections - terminals | wire (AWG 24...AWG 18) |
| Type of installation | immersion |
| Length | 70-70 mm for side sensor |
| Former part number | 5123158010 |
| Time constant | 1500 ms |
| Environment | |
| Product certifications | CE |
