The Easergy T300 battery are designed for long power supply The output voltage is 12VDC The battery life is 10 years The operating temperature is -15°C to + 50°C during the charge and -20°C to + 60°C during the discharge. The storage temperature is -20°C to + 60°C. Mechanical dimensions are 125 mm in height, 175 mm in width and 166 mm in depth.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Device short name | BAT24AH |
| Product compatibility | ITI3, PS100, PS50 |
| Internal resistance | 20.47 mOhm conforming to IEC 60896-21 |
| Battery type | VRLA |
| Short-circuit current | 714 A conforming to IEC 60896-21 |
| Transfer impedance | 8.5 mOhm at 1 kHz |
| Range of product | PowerLogic T300 |
| Output voltage | 12 V DC |
| Complementary | |
| Depth | 166 mm |
| Width | 175 mm |
| Battery capacity | 25 Ah |
| Battery life | 10 year(s) at 20 °C conforming to EUROBAT |
| Tightening torque | 2.5 N.m |
| Self-discharge rate | 3 %, 1 month at 20 °C |
| Connector type | M5 |
| Net weight | 9.8 kg |
| Height | 125 mm |
| Environment | |
| Ambient air temperature for storage | -20-60 °C |
| Ambient air temperature for operation | -20-60 °C discharge, -15-50 °C charge |
