TeSys Deca instantaneous auxiliary contact block with dust and damp protected contacts, for LC1D contactors and CAD control relays in harsh industral environments. It provides 1NO + 1NC protected contacts rated up to 0.1A 125V AC / 30V DC, connection by screw clamp terminals. Very low minimum switching capacity (5V / 1mA) thanks to gold alloy contact material. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC, EAC).
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Device short name | LA1 |
| Auxiliary contacts operation | instantaneous |
| Range | TeSys |
| Range of product | TeSys Deca |
| [Ie] rated operational current | 0.1 A |
| [Ui] rated insulation voltage | 250 V conforming to IEC 60947-5-1 |
| Pole contact composition | 1 NO (sealed) + 1 NC (sealed) |
| Mounting location | front |
| Product name | TeSys Deca |
| Product or component type | auxiliary contact block |
| Range compatibility | TeSys Deca LC1D, TeSys Deca CAD, TeSys F CR1F, TeSys F LC1F, TeSys D LC1D, TeSys D CAD |
| [Ue] rated operational voltage | 30 V DC for protected contact, 125 V AC for protected contact |
| Standards | GB/T 14048.5, CSA C22.2 No 60947-5-1, UL 60947-5-1, EN/IEC 60947-5-1 |
| Product certifications | UKCA, EAC, CCC, CSA, UL, CB |
| Complementary | |
| Compatibility code | LA1 |
| Mechanical durability | 5 Mcycles |
| Tightening torque | 1.7 N.m - with screwdriver pozidriv No 2, 1.7 N.m - with screwdriver Philips No 2, 1.7 N.m - with screwdriver flat Ø 6 mm |
| Minimum switching voltage | 5 V |
| Connections - terminals | screw clamp terminals 2 cable(s) 1-2.5 mm²rigid, screw clamp terminals 1 cable(s) 1-2.5 mm²rigid, screw clamp terminals 2 cable(s) 1-2.5 mm²flexible without cable end, screw clamp terminals 2 cable(s) 1-2.5 mm²flexible with cable end, screw clamp terminals 1 cable(s) 1-2.5 mm²flexible without cable end, screw clamp terminals 1 cable(s) 1-2.5 mm²flexible with cable end |
| Height | 48 mm |
| Shielding continuity terminal | without |
| Depth | 39 mm |
| Width | 44 mm |
| Net weight | 0.04 kg |
| Insulation resistance | > 10 MOhm |
| Minimum switching current | 1 mA |
| Environment | |
| Protective treatment | TH conforming to IEC 60068 |
| Environmental characteristic | harsh environment |
| Ambient air temperature for storage | -25-70 °C |
| IP degree of protection | IP2X conforming to IEC 60529 |
| Ambient air temperature for operation | -25-70 °C |
