TeSys K contactor, 3 poles (3NO), for motor control applications up to 9A/690V AC-3 (4kW@400V), and for non-inductive load control applications up to 20A/690V AC-1. It provides a 48V 50/60Hz AC coil, 1NO built-in auxiliary contact, connection by solder pins for printed circuit boards. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC).
Only registered users can write reviews
Related products
Auxiliary contact block, TeSys K, 1NO+3NC, front mounting, screw clamp terminals
LA1KN13
Auxiliary contact block, TeSys K, 1NO+3NC, front mounting, screw clamp terminals
$74.69 inc GST
$29.64 inc GST
Auxiliary contact block, TeSys K, 4NC, front mounting, screw clamp terminals
LA1KN04
Auxiliary contact block, TeSys K, 4NC, front mounting, screw clamp terminals
$71.28 inc GST
$28.29 inc GST
Auxiliary Contact Block, TeSys k, TeSys K, 1NO + 1NC, front mounting, screw clamp terminals
LA1KN11
Auxiliary Contact Block, TeSys k, TeSys K, 1NO + 1NC, front mounting, screw clamp terminals
$40.04 inc GST
$15.89 inc GST
Auxiliary Contact Block, TeSys k, TeSys K, 2NC,front mounting, screw clamp terminals
LA1KN02
Auxiliary Contact Block, TeSys k, TeSys K, 2NC,front mounting, screw clamp terminals
$40.15 inc GST
$15.94 inc GST
Auxiliary Contact Block, TeSys k, TeSys K, 2NO + 2NC, front mounting, screw clamp terminals
LA1KN22
Auxiliary Contact Block, TeSys k, TeSys K, 2NO + 2NC, front mounting, screw clamp terminals
$72.27 inc GST
$28.68 inc GST
Auxiliary Contact Block, TeSys k, TeSys K, 2NO, front mounting, screw clamp terminals
LA1KN20
Auxiliary Contact Block, TeSys k, TeSys K, 2NO, front mounting, screw clamp terminals
$40.15 inc GST
$15.94 inc GST
Auxiliary Contact Block, TeSys k, TeSys K, 3NO + 1NC, front mounting, screw clamp terminals
LA1KN31
Auxiliary Contact Block, TeSys k, TeSys K, 3NO + 1NC, front mounting, screw clamp terminals
$71.39 inc GST
$28.33 inc GST
Auxiliary Contact Block, TeSys k, TeSys K, 4NO, front mounting, screw clamp terminals
LA1KN40
Auxiliary Contact Block, TeSys k, TeSys K, 4NO, front mounting, screw clamp terminals
$72.05 inc GST
$28.60 inc GST
clip-on marker holder, 8x17mm, for TeSys k contactor or reversing contactor
LA9D90
clip-on marker holder, 8x17mm, for TeSys k contactor or reversing contactor
$0.97 inc GST
$0.38 inc GST
Electronic time delay Auxiliary Contact Block, TeSys k, TeSys K, 1C/O, on delay 1-30s, front, control 24-48 V AC/DC
LA2KT2E
Electronic time delay Auxiliary Contact Block, TeSys k, TeSys K, 1C/O, on delay 1-30s, front, control 24-48 V AC/DC
$139.48 inc GST
$55.36 inc GST
energy sensor PowerTag Flex 63A 3P top and bottom position
A9MEM1573
energy sensor PowerTag Flex 63A 3P top and bottom position
$280.50 inc GST
$202.66 inc GST
