Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Product specific application | for multi-racks configuration |
| Product or component type | extendable rack |
| Range of product | Modicon Premium Automation platform |
| Complementary | |
| Product compatibility | TSXPSY power supply, specific application module, I/O module, TSXP57 processor |
| Number of slots | 12 |
| Fixing mode | by clips (35 mm symmetrical DIN rail), by 4 M6 screws (panel) |
| Net weight | 2.34 kg |
| Marking | CE |
| Electrical connection | 2 connectors female SUB-D 9 (remote connection of bus X) |
| Environment | |
| Operating altitude | 0...2000 m |
| IP degree of protection | IP20 |
| Protective treatment | TC |
| Relative humidity | 5-95 % without condensation for storage, 10-95 % without condensation for operation |
| Ambient air temperature for storage | -25-70 °C |
| Pollution degree | 2 |
| Standards | IEC 61131-2, 73/23/EEC, CSA C22.2 No 213 Class I Division 2 Group C, UL 508, CSA C22.2 No 142, 89/336/EEC, 93/68/EEC, CSA C22.2 No 213 Class I Division 2 Group B, 92/31/EEC, CSA C22.2 No 213 Class I Division 2 Group D, CSA C22.2 No 213 Class I Division 2 Group A |
| Ambient air temperature for operation | 0-60 °C |
| Product certifications | RMRS, RINA, BV, LR, DNV, GL, ABS |
