VG311F Globe Valve, 3-Way, DN150, Flanged, Kvs 300 mÂ³/h, Cast Iron Body and Seat, Brass Plug.

Manufacturer: Schneider Electric

SKU: VG311F-150C

GTIN: 3606489646301

Instruction sheet

Old price: $5,308.60 inc GST

Price: $7,020.62 inc GST

Qty:

Supported cards

Full Description
Specifications
Reviews

The globe valve VG311F is a large 3-way globe mixing valve designed for a wide range of heating and cooling applications. The valve uses a crown plug for media with a very high rangeability

Products specifications

Attribute name	Attribute value
Main
Operating fluid temperature	-10-150 °C
Body material	grey cast iron GG-25
Seating seal material	Port A:metal to metal
Seat leakage	Port A: Less than 0.03 % of kvs
Product or component type	valve
Targeted region	Australia., Asia Pacific., Europe
Valve connection size	DN150 (ISO 7005-2)
Seat material	Port B: grey cast iron GG-25, Port A: grey cast iron GG-25

Medium compatibility	Water, Glycol 50 %, Glycol 30 %, Glycol 25 %
Control valve rangeability	greater than 50:1
Plug material	CB491K bronze
Valve product series	VG311F
Flow coefficient	300 kvs, 173.43 cv
Stem flow action	Stem up closes A and opens B to AB
Valve configuration	3-Way
Stem movement	linear
Pressure fluid max delta P normal life	29 psi
Valve type	globe
Valve model	VG311F-150C 300M SU00
Packing material	EPDM (ethylene propylene diene monomer)
Valve connection type	flanged
Stem seal material	EPDM (ethylene propylene diene monomer)
Flow characteristic	equal percentage
Trim material	brass
Stroke length	45 mm
Stem material	stainless steel AISI 303
Pipe size	150 mm
Pressure class	PN16
Body size	150 mm (6 in)
